Yanzeo R26 High-Speed 2D Barcode Scan Engine, Embedded Module with USB & RS232 Interface

Resolution:

640×480 CMOS

Power:

0.7W (operating); 0.01W (standby)

Scanning mode:

Sensing Mode

Current:

Less than 230 mA (working); 5 mA (standby)

Scanning angle:

Horizontal 72°, vertical 57°, rotation 360°

Casing material:

PC+ABS

Accuracy:

≥4mil

Temperature:

0℃ to 50℃ (operating); -40℃ to 60℃ (storage)

System interface:

USB keyboard; USB virtual serial port; RS-232 serial port

Humidity:

5% to 95% (non-condensing)

Appearance size:

65mmL×61mmW×32mmH

Weight:

20g

Decoding capability:

2D：QR Code, Data Matrix (DM）, PDF417, Han Xin, Micro PDF417, Micro QRCode, MaxiCode, Aztec Code, Code16K, etc

1D：EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, ChinaPost 25, GS1 Composite, etc.
